Nch 60V 190A, PDFNWB5x6-8L, SGT Power MOSFET
| Part Number | Status | ESD Yes/No |
VDS V |
VGS V |
ID A |
VGS(TH) V |
RDS(mΩ)@VGS 10V Typ |
RDS(mΩ)@VGS 10V Max |
RDS(mΩ)@VGS 4.5V Typ |
RDS(mΩ)@VGS 4.5V Max |
Package |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CJAC2R8SN06AL | Active | No | 60 | ±20 | 190 | 1.2~2.4 | 2.1 | 2.8 | 3.1 | 4.3 | PDFNWB5x6-8L |
| Part Number | Package Type | Component Weight(g) | Marking | Packing Info | MSL |
|---|---|---|---|---|---|
| CJAC2R8SN06AL | PDFNWB5x6-8L | CJAC2R8SN06AL | Tape&Reel:5Kpcs/Reel | MSL1 |
